• Mechanical Life:1000 operations
• Operations Force:500gf • Stroke:0.6mm • Operation Temperature Range: -40°Cto +85°C.
• Storage temperature Range:-40°Cto +85°C.
• Electrical Life:1000 operation cycles
• Non-Switching Rating:100mA,50VDC.
• Switching Rating:25mA,24VDC.
|
 |
   |
| Part Number | Mechanical Life | Operations Force | Stroke | Operation Temperature Range | Electrical Life | Non-Switching Rating | Switching Rating | PDF下載 |
|---|---|---|---|---|---|---|---|---|
| RHN | 1000 operations | 500gf | 0.6mm | -40℃ to +85℃ | 1000 cycles | 100mA,50VDC | 25mA,24VDC | 暫無(wú) |
| RHNF | 1000 operations | 500gf | 0.6mm | -40℃ to +85℃ | 1000 cycles | 100mA,50VDC | 25mA,24VDC | 暫無(wú) |
